FACTORYBOARD INSULATON
Product Description
Factoryboard is a rigid board manufactured from non-combustible Glasswool insulation. Available in 25mm, or 50mm thickness. It can be supplied with tested reinforced foil or white metalised foil. Alternative facings are also available (white embossed vinyl or black non-woven glass tissue).
Applications
Multi-purpose wall cladding:
- Use 80 kg/m3 density
- Must be installed using Aluminium H/T-sections
Over purlin roof insulation for new buildings or in a supporting grid system for existing buildings
- Use 80 kg/m3 density in horizontal applications
- Should not be installed in applications where the facing material is exposed to direct or indirect ultraviolet radiation
- Must be installed using Aluminium H/T-sections
BOQ Specs
Install (25mm / 50mm) thick, rigid Factoryboard as an aesthetic, acoustic and thermal (wall cladding/suspended ceiling/over purlin roof insulation). Density 80 kg/m³ faced with (reinforced foil/white metalised foil/white embossed vinyl/black non-woven glass tissue). Install as per manufacturer’s specifications.
Physical & Thermal Properties
- 40mm Thickness discontinued
